To provide additional support to developers working with the MIPI A-PHY℠ v1.0 specification, the A-PHY Working Group has released an Application Note for MIPI A-PHY Specification v1.0: Profile 1 and Profile 2 (for MIPI members), providing key performance indicators to help implementers design solutions that conform to the automotive long-reach serializer-deserializer (SerDes) physical layer specification.
MIPI A-PHY℠ v1.0 has now crossed an important milestone on its path toward adoption as an IEEE standard.
On 10 February, the MIPI A-PHY adoption PAR (Project Authorization Request), known as "IEEE P2977™ Adoption of MIPI Alliance Specification for A-PHY Interface (A-PHY) Version 1.0," was approved by the IEEE Standards Association (IEEE SA) Standards Board, following a recommendation by the organization's New Standards Committee. The IEEE SA Corporate Advisory Group served as the project's sponsor.
Next-generation vehicles are rewriting the rulebooks when it comes to high-speed data interfaces. With the implementation of advanced driver assistance systems, high-definition in-vehicle infotainment and autonomous driving systems, the number of onboard cameras, sensors, displays and computing systems is increasing significantly—placing huge bandwidth demands on in-vehicle data interfaces.
MIPI Alliance is rolling out a portfolio of Protocol Adaptation Layers (PALs) to support a range of important automotive sensor and display applications—advanced driver assistance systems (ADAS), autonomous driving systems (ADS) and in-vehicle infotainment (IVI), among others. The PALs enable upper-layer protocols such as MIPI Camera Serial Interface (CSI-2®) and Display Serial Interface (DSI-2SM) to be transported over MIPI A-PHYSM, the first industry-standard, long-reach serializer-deserializer (SerDes) physical layer interface.
Raj Kumar Nagpal, interim chair of the MIPI PHY Working Group and lead of the MIPI A-PHY Subgroup, talks about how the PALs support A-PHY, as well as their contribution to the broader system of MIPI automotive connectivity solutions currently under development.
MIPI interface protocols are widely used in automotive to connect cameras, sensors, displays and other components to automotive systems on chips (SoCs). In a previous blog post, I detailed the automotive applications of MIPI CSI-2® and MIPI DSI-2SM, MIPI’s camera and display protocols, which have been broadly implemented in the industry. In September, the Alliance released MIPI A-PHYSM v1.0, the first asymmetric industry-standard, long-reach serializer-deserializer (SerDes) physical layer interface. In this post, I'll take a deep dive into MIPI A-PHY and provide a look at its key features and how they benefit some common automotive applications.
